NLE15LNDX
NLE Plus · R290 · 105H7500
The NLE15LNDX tops the NLE Plus series with 15 cm³ of displacement for R290 (propane), combining compact size with the cooling capacity of larger platforms. It was developed to support the IEC approvals for hydrocarbon charges from 150 g to 500 g in supermarket freezers, stainless steel cabinets and double glass door merchandisers.
Target applications: supermarket freezers, stainless steel freezers, and double-glass-door merchandisers.
Technical Data
- Refrigerant: R290 (propane)
- Application: LBP
- Capacity Q0 (ASHRAE LBP): 775 W
- COP (ASHRAE LBP): 1.71 W/W
- Capacity Q0 (EN 12900, -35 °C): 438 W
- Evaporating temp. range: -40 to -5 °C
- Voltage range: 198-254 V / 50 Hz
- Approvals: VDE
- Displacement: 15 cm³
