BD Nano EV
BDN-EV · R134a, R1234yf · 109Z0700 + 101N2830
The BD Nano EV cools refrigerators in electric vehicles from a compressor 93 mm high weighing 1.38 kg, freeing cabin space for food and drinks. Its control unit is smaller and lighter than previous BD Nano Automotive units and carries LIN connectivity, delivering and receiving operational data in real time over Modbus.
Target applications: refrigerators and center consoles in electric passenger cars.
Technical Data
- Refrigerant: R134a, R1234yf
- Application: LBP / MBP
- Cooling capacity (ASHRAE LBP): 27.5 to 36.2 W (R134a) | 30.3 to 39.9 W (R1234yf)
- COP (ASHRAE LBP): up to 1.41 W/W (R134a) | up to 1.44 W/W (R1234yf)
- Evaporating temp. range: -30 to -5 °C
- Nominal voltage: 12 V DC (range 9.6-17 V)
- Speed range: 2,300 - 3,000 rpm
- Electronic unit: 101N2830, 0.055 kg
- Communication: LIN hardware, Modbus protocol
- Mechanical: ISO 16750 compliant
- Manufacturing: IATF 16949 certified plant, Tianjin
- Height and weight: 93.3 mm · 1.37 kg compressor
