SC15GH
S-Series · R1234yf, R513A · 104G8561
The SC15GH is a high back pressure compressor with 15.28 cm³ of displacement, approved for R1234yf and R513A. It delivers 1,387 W at ASHRAE HBP with a COP of 2.39 and holds its performance across a 198 to 254 V supply range.
Target applications: domestic hot water heat pumps with tanks of up to 200 liters, enclosure systems and edge data centers.
Technical Data
- Refrigerant: R1234yf, R513A
- Application: HBP
- Capacity Q0 (ASHRAE HBP): 1,350 W (R1234yf) | 1,425 W (R513A)
- COP (ASHRAE HBP): 2.39 W/W (R1234yf) | 2.37 W/W (R513A)
- Capacity Q0 (ASHRAE MBP): 742 W, COP 1.60 W/W
- Voltage range: 198-254 V, 220-240 V / 50 Hz and 208-230 V / 60 Hz
- Motor type: CSIR, high starting torque
- Approvals: VDE
- Displacement: 15.28 cm³
