• FRK-Series Compressors

    Hermetic Refrigeration Compressors
    for AC Voltage

    Sales Request   Technical Support

    • Next-generation hermetic AC compressors with maximum efficiency featuring the tried and trusted quality of our
      FR and FF compressors (F-Series)
  • Heavy Duty Robustness
    The successor of our legendary FR and FF compressors, reliable even under harsh conditions

  • Optimized Muffler System
    For heavy duty applications with rapid load changes, extreme liquid return conditions, and oil foaming

  • Excellent Efficiency
    High COP and top efficiency for light commercial applications

  • Broad Application Range (L/M/HBP)
    Robust solution for food retail and food service applications

  • Easier Application Assembly
    New terminal board design for additional interconnections

  • Wide Voltage Range at 50 or 60 Hz
    Ideal for regions that experience harsh and challenging environments

Technical Details

Refrigerants R134a, R513A
Nominal Voltage 220 V
Voltage Range 170–254 V, 198–254 V
Frequency Range 50 / 60 Hz
Displacement 4–8.6 cm³
Variable Speed Variants Available no
Ultra-Low Temperature Models Available no
LBP 99–287 W
MBP 215–590 W
HBP 386–1031 W
L-MBP yes
M-HBP yes
L-M-HBP yes
Use

Find Your Product in Our Selector

FRK-Series

Typical Applications

  • Glass door merchandiser

    Glass d. merchandiser

  • Horizontal glass door freezer

    Glass door freezer

  • Ice maker

    Ice maker

  • Stainless steel freezer

    Stainless steel freezer

  • Vending machine

    Vending machine

  • Water cooler / Water fountain

    Water cooler / Water fountain

  • Condensing unit

    Condensing unit

  • Air dryer / Dehumidifier

    Air dryer / Dehumidifier

Technical Literature

  • FRK-Series Compressors, R134a, R513, 220-240 V, 50/60 Hz & 208-230 V, 60 Hz

    FRK-Series Compressors, R134a, R513, 220-240 V, 50/60 Hz & 208-230 V, 60 Hz

    | Literature | Leaflets

    Download (451.30 KB)
  • Hermetic Compressors, R134a · R513A, R404A · R452A

    Hermetic Compressors, R134a · R513A, R404A · R452A

    | Literature | Quick References

    Download (13.11 MB)
  • Hermetic Compressors, 60 Hz, R134a · R513A, R404A · R452A, R290, R600a

    Hermetic Compressors, 60 Hz, R134a · R513A, R404A · R452A, R290, R600a

    | Literature | Quick References

    Download (22.78 MB)
  • Hermetic Compressors for AC Voltage

    Hermetic Compressors for AC Voltage

    | Literature | Catalogs

    Download (46.34 MB)
