ULT Stationary Cascade Condensing Unit
2× MS18UVULTM · R170, R290, R1270 · 104M0825 + 105N4932
The ULT stationary cascade condensing unit pairs two MS18UVULTM variable-speed compressors, R170 (ethane) on the low stage and R290 (propane) or R1270 (propene) on the high stage. It ships assembled with oil separator, internal heat exchangers and controllers, and holds a freezer compartment of up to 900 liters at -86 °C.
Target applications: stationary ultra-low temperature freezers and biomedical or vaccine storage up to 900 liters.
Technical Data
- Refrigerant: R170 (ethane) low stage · R290 (propane) or R1270 (propene) high stage
- Application: Ultra-low temperature freezers
- Freezer compartment temp.: -20 to -86 °C
- Compartment size at -86 °C: up to 900 liters
- Evaporating temp. range: -90 to -60 °C
- Compressor ambient range: +10 to 43 °C
- Electronic units: 2× 105N4932 Multipurpose multi-voltage
- Input voltage: 80-270 V, 50-60 Hz
- Dimensions (H × W × D): 300.4 × 840.3 × 511 mm
- Weight: 47.68 kg
