BD Nano Automotive for Trucks and ICE Cars
BDN45F-A.2 · 109Z0740 + 101N3000
Secop’s BDN45F-A.2 is the next generation automotive compressor which delivers premium cooling performance, high efficiency, and low noise and vibration levels in a compact design for cars, trucks, and buses. BD Nano Automotive.2 compressors BN45F-A.2 cool refrigerators in passenger cars, trucks and buses with the same cooling capacity as much larger BD35F/50F compressors.
Target applications: refrigerators in passenger cars with internal combustion or electric drive, trucks, and buses.
Technical Data
- Refrigerant: R134a, R1234yf (BDN45F-A.2)
- Application: LBP / MBP
- Cooling capacity (ASHRAE MBP): 61.7 to 125.5 W (R1234yf)
- Cooling capacity (ASHRAE LBP): 30.3 to 64.1 W (R1234yf)
- Evaporating temp. range: 12 V DC: -30 to 0 | 24 V DC: -30 to -5
- Nominal voltage: 12 / 24 V DC (range 8.5-17 V, 19-34 V)
- Speed range: 12 V DC: 2,300-3,000 | 24 V DC: 2,300-4,500
- Electronic unit: 101N3000, 0.072 kg
- EMC: CISPR 25 class 5
- Mechanical: ISO 16750 compliant
- Manufacturing: IATF 16949 certified plant, Tianjin
- Height and weight: 93 mm · 1.5 kg with controller
